AC220V 80W/K Enclosure Heat Exchanger For Telecom Cabinet

Name: AC220V 80WK Enclosure Heat Exchanger For Telecom Cabinet
Brand: ESTEL
Price: 1 USD

China AC220V 80W/K Enclosure Heat Exchanger For Telecom Cabinet wholesale

Brand Name : ESTEL

Model Number : HE06-80SEH/01(AC220V Type)

Certification : ISO9001, CE,

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T, Western Union, Paypal

Delivery Time : 2-3 weeks

Packaging Details : carton, wooden case

heat exchange capacity : 80W/K

rated input power : 100W

rated input voltage : AC220V/50Hz

rated input current : 0.5A

rated heating capacity : 300/500W optional

Noise : ≤65dB

MTBF : 70000 hours

Weight : 18kg

Contact Now

AC220V 80W/K Enclosure Heat Exchanger Intelligent Temperature Control Remote Monitor For Outdoor Telecom Cabinet

1. Application Range

This heat exchanger is designed to install on the communication or network cabinets.

Use on the inside and outside the thermal cycling system form the effective separation of heat exchange system, realize to accumulation quantity of heat inside the cabinet.

2. Technical Data

Model No.		HE06-80SEH/01(AC220V Type)
Noise		≤65dB
IP Grade		IP55
Weight		18kg
Environmental Performance	working environmental temperature	-20°C ~ 55°C
	storage working temperature	-40°C ~ 70°C
	working humidity	≤95%
Thermal Performance	rated heat exchange capacity	80W/K
Thermal Performance	rated heating capacity	300/500W (optional)
Electrical Performance	rated input current	0.5A
	rated input power	100W
	rated input voltage	AC220V/50Hz
Reliability	MTBF	70000 hours

3. Dimension Diagram:

430×176×700 mm (W×D×H)

Size

Spec

Model No.

80W/K Heat Exchanger

HE06-80SEH/01

300

401

450

600

672

700

133

176

649

379

430

4. Advantage

(1) Enclosed air circuit cooling system design, which make the inside air and outside air isolated and effectively avoid contamination from outside.

(2) Avoid dew formation from too cold.

(3) Compact structure and convenient installation & maintenance.

(4) It can be remote monitored.

(5) The main components are international brand which greatly improves the reliability of the system.

5. System Principle Diagram

AC220V 80W/K Enclosure Heat Exchanger For Telecom Cabinet

6. Product Application Case

AC220V 80W/K Enclosure Heat Exchanger For Telecom Cabinet

7. Product Picture

AC220V 80W/K Enclosure Heat Exchanger For Telecom Cabinet
